167 Kva Single Phase Pole Mounted Transformer

VKE supplies power pole mounted transformer. It can reduce the length of low-voltage distribution lines, reduce line losses, and improve the quality of power supply. The transformer is designed with high efficiency and energy-saving coil core structure. The transformer is characterized by small volume, small infrastructure investment, reduced radius of low-voltage power supply and more than 60% loss of low-voltage line. Adopts fully sealed structure, with strong overload capacity, high reliability of continuous operation and simple maintenance. It is suitable for rural power grid, remote mountainous areas, scattered villages, agricultural production, lighting and power consumption, and can also be used for energy-saving transformation of railway and urban power grid. Our transformer was designed with advanced technology and adopts high quality material and components which result in reliable quality and long operation time.

VKE ensure each one of our delivered transformers had passed the full acceptance test and we remains 0 fault rate record for more than 10 years so far, oil immersed power transformer is designed in accordance with IEC, ANSI and other major international standards.

Installation method: Pole installation, including single pole or double pole. It can be customized according to the customer's requirements and is quite suitable for outdoor power conversion.

Phase number: Single-phase, which can be applied in many scenarios and is suitable for Europe and America.

Cooling method: Oil-immersed, natural cooling.

Iron core

167 kva single phase pole mounted transformer is made by stacking high-permeability silicon steel sheets, reducing hysteresis loss and eddy current loss, and improving the efficiency of electrical energy conversion.

Winding

High-voltage winding: 167 kva single phase pole mounted transformer mostly uses enameled copper wire or aluminum wire, wound on the outside of the iron core, with a relatively large number of turns.

Low-voltage winding: It has fewer turns and is insulated and isolated from the high-voltage winding. Voltage conversion is achieved through electromagnetic induction.

Fuel tank and oil-immersed system

Most pole-mounted transformers are oil-immersed, with transformer oil filled in the oil tank, which serves both insulation and heat dissipation functions. The surface of the fuel tank is usually equipped with heat sinks to enhance the heat dissipation effect.

Casing

There is a set of insulating bushings on both the high-voltage side and the low-voltage side, which are used to lead out the winding connection, isolate the live parts from the oil tank, and ensure operational safety.

1.High-voltage side

For short-circuit protection, corresponding drop-out fuses need to be equipped. To prevent lightning strikes, lightning arresters need to be equipped.

2.Low-pressure side

Outgoing lines can be reserved according to actual needs. It is convenient for wiring and installation of low-voltage distribution boxes.

3.Nameplate

Mark the key information of the transformer such as model, capacity, voltage, frequency, manufacturer and production date for easy identification and maintenance.
